Mosconi High-End DSP Processor 8ch Input 12ch Output - Made in Italy
Overview
- 8-channel input
- 12-channel output
- High resolution
- 6to8 audio performance
- 1 x digital IN / direct-audio-streaming (optional)
- 48 kHz/24 Bit High Resolution-Audio
High Resolution BT Pure Digital Direct Streaming
You love music in highest sound quality!
With the optional MOS-BTS you play your music lossless. The best part is, it happens wirelessly via BT. Just start your music on your smartphone or tablet and the DSP just plays it. How the DSP knows what to do... ATOM Auto Fade Trigger Option Menu!
Specifications
- ANALOG INPUTS: 8 (RCA)
- ANALOG OUTPUTS: 12 (RCA)
- DIGITAL INPUTS: 1 coaxial (RCA) or 1 optical (toslink) or MOS-BTS (optional)
- Selectable with switch
- DIGITAL OUTPUTS: no
- NATIVE SAMPLE RATE: 96 kHz / 24 Bit
- DSP PERFORMANCE: 294.912 MHz, 32-bit Sigma DSP
- 3072 SIMD instructions per sample at 96 kHz
- ASRCs from 1:8 up to 7.75:1 ratio and 139 dB DNR
- ADC PERFORMANCE: Burr Brown 24-Bit
- 107 dB Dynamic Range
- -93 dB THD+N
- DAC PERFORMANCE: Burr Brown 24-Bit
- 112 dB Dynamic range
- -94 dB THD+N
- Differential voltage output
- INPUT MODE: Low Level (LL) / High Level (HL)
- INPUT IMPEDANCE: 12Kohm (LL) / 47ohm (HL)
- INPUT SENSITIVITY: 1.2Vrms ÷ 8Vrms (LL) / 3Vrms ÷ 20Vrms (HL)
- INPUT REGULATION: -16.5dB ÷ 0dB
- MAX OUTPUT SIGNAL: 8Vrms
- OUTPUT IMPEDANCE: 56 ohm
- HARDWARE MUTE: no
- S/N RATIO: >100dB "A"
- THD DISTORTION: <0.003% @ 4Vrms
- FREQUENCY RESPONSE: 10Hz ÷ 40KHz
- CHANNEL SEPARATION: >90dB (@ 100Hz)
- CHANNEL SEPARATION: >90dB (@ 1KHz)
- CHANNEL SEPARATION: >70dB (@ 10KHz)
- SUPPLY VOLTAGE: 10V ÷ 16V (6V tolerant to sustain engine crank)
- DC-DC CONVERTER: transformer coupled, Current-Mode, Flyback converter
- CONVERSION FREQUENCY: 52KHz
- AUTOSENSE: OFF / BTL / SE
- SEPARATE REMOTE OUT: yes, 100mA max. (protected)
- COMMUNICATION: USB, RCD/RC-MINI (optional), MOS-BTM (optional), RTC-HUB (optional)
- MISCELLANEOUS: Gold finishing PCB
