Atoll Evolution Integrated Pre-Amplifier - Made in France
Overview
The PR300 EVO belongs to ATOLL’s “Evolution” range of preamplifiers. It has a wide range of combinations with considerable improvements.
Features
- 8 mm brushed, micro-blasted and anodized aluminum front panel, high-precision engraving.
- 1.5 mm steel chassis.
- Two 10 VA toroidal transformers each for the audio stages.
- A 3.2 VA linear transformer (digital audio).
- A 5 VA low-consumption transformer (control logic).
- High-quality and shielded MKP link capacitors.
- Integral dual mono and symmetrical structure:
- – Two independent symmetrical stages for each channel.
- – One stereo attenuator per channel (with switched resistors).
- Audio stages with bipolar transistors with perfectly symmetrical structure, polarized in class A, very low feedback rate.
- Precise balance adjustment, possibility of memorizing it.
- Possibility of renaming the inputs.
- Possibility of choosing the standby mode: Low consumption or preheating.
- High-contrast OLED display (on or off mode after 5 seconds of inactivity).
- ATOLL global remote control supplied as standard.
- The PR300 EVO is compatible with DA100 and DA200 boards (optional):
- – DA100 and DA200.
- – P50 and P100.
CONNECTIVITY
Inputs
- 1 XLR input.
- 5 Line inputs: AUX or PHONO (option) CD, TUNER, DVD, TAPE.
- 1 BY-PASS input.
Outputs
- 2 Line outputs.
- 1 XLR output.
- 1 12V Trigger output.
Possibility of adding the DA200 digital board (optional):
- 2 Optical inputs (24 bits/192 kHz).
- 2 Coaxial inputs (24 bits/192 kHz).
- 1 Asynchronous USB input (24 bits/384 kHz) & DSD (up to 256).
- 1 Bluetooth input.
Specifications
- Power supply: 2×10 VA (audio) + 10 VA + 3,2 VA
- Total of capacitors: 89 000 µF
- Bandwidth (-3 dB): 5 Hz – 100 kHz
- Rise time: 1.3 µs
- Input impedance: 357 kΩ
- Sensitivity: 3 V
- Signal-to-noise ratio: 100 dB
- Distortion rate at 1 kHz: 0,005%
- Standby power consumption (low power): < 0,5 W
- Dimensions: 440×365×95 mm
- Weight: 6.8 Kg
