AV100 - Made in France
Features
- Aluminium front panel of 4 mm
- Complete steel chassis of 1,5 mm
- Fully symmetrical stages with discrete components
- Single pair of MOS-FET transistors per channel on outputs
- Double 340VA toroïdal transformers
Specifications
- Efficacy power: 100 W /ch /8W 140 W /ch /4W
- Impulsion power: 180 W /ch
- Power supply: 680 VA
- Total of capacitors: 45 000 mF
- Number of Inputs: 3
- Input impedance: 47 kW
- Sensitivity: 1,77 V
- Signal/Noise: 100 dBA
- Distortion at 1kHz: < 0,05%/30W
- Frequency response: 5Hz-200kHz
- Rise Time: 1,3 ms
- Dimensions: 440x90x290mm
- Weight: 10 kg
